Product Description
Introducing the 4200R Exit Device, the pinnacle of safety and reliability for commercial applications. This wide stile rim exit device, also known as the 4200R rim panic device, combines robust construction with sleek design, ensuring both security and aesthetic appeal. With multiple finish options including 605(US3) and 630(US32D), it suits any architectural style. Certified to UL 305 and UL 10C for 90-minute fire doors, it guarantees top-notch performance and compliance. Backed by a five-year warranty, the 4200R exit device is your go-to choice for superior emergency egress solutions. Contact a sales rep and choose PDQ for unmatched quality and peace of mind.
Docs & Downloads:
Discover the versatility of our 4200R Exit Device series, offering premium protection with a variety of finishes.
- Choose from 6-Finishes: 605(US3), 626(US26D), 630(US32D), 689(US28), 695(SP313), 696(US4)
Crafted for durability and security, our wide stile rim exit device ensures peace of mind while enhancing the appeal of your space. Experience safety and style seamlessly integrated with our 4200R Rim Panic Device.
Features & Benefits
Certifications
Our cutting-edge 4200R Exit Device series boasts a prestigious array of certifications, ensuring unparalleled safety and compliance.
- UL 305 certification guarantees superior quality, while
- UL 10C listing for 90-minute fire doors up to 3’ x 7’ provides peace of mind in emergency situations.
- Compliant with ADA (Americans with Disabilities Act) and ICC/ANSI 117.1 standards, our wide stile rim exit device offers accessibility without compromising security.
Elevate your space with confidence, knowing that our 4200R Rim Panic Device meets the most rigorous industry requirements, safeguarding both property and occupants. Trust in our certified solutions to exceed expectations and deliver unmatched reliability in every application.
Specifications
Explore the unmatched capabilities of our 4200R Exit Device. Crafted with precision engineering and robust materials, our 4200 Series rim exit device ensures unparalleled security and reliability for your commercial spaces.
| CHASSIS: | • Corrosion resistant plated steel |
| RAIL: | • Heavy gauge steel or stainless steel |
| LATCH: | • RIM (R) – 3/4” throw* |
| BACKSET: | • 2-3/4” Backset Compatible with 161 prep |
| HAND: | • Device is non-handed |
| DOGGING: | • Hex key dogging standard • Dogging not available on fire listed devices |
| MINIMUM STILE WIDTH: | • 4-1/4”for device (exit only) • Minimum stile requirements with trim varies by trim type |
| DOOR THICKNESS: | • 1-3/4” standard |
| DOOR WIDTH: | • Standard for 3 ft doors, option available for doors up to 4’ |
| FINISHES: | • 626 Satin Chrome, 630 – Satin Stainless Steel, 689 – Aluminum, 695 - Duro Bronze, 696 – Gold |
| FASTENERS: | • Includes machine screws and wood screws • Sex nuts supplied with all Fire Listed devices |
| WARRANTY: | • Five (5) year limited warranty |
| CERTIFICATIONS, LISTINGS, COMPLIANCES: | • UL 305 listed for “Panic” , UL listed for “Fire Exit Hardware” labeled for up to 1-1/2 hours, 3’0” x 7’0” Max Size • Complies with ADA (Americans with Disabilities Act) and ICC/ANSI 117.1 for Accessible and Usable Buildings • TAA compliant. Country of origin: Taiwan |
Finishes
Explore a diverse selection of premium finishes for the 4200R Exit Device from our 4200 Series. Elevate your space with finishes blending style and durability, tailored to complement any design aesthetic. Choose the perfect finishing touch for your project with our wide stile rim exit device.
