Product Description
For commercial applications, PDQ’s 4200R rim exit device is a safe and reliable solution. This wide stile rim exit device ensures both security and style through its tough design and elegant design. With its multiple finish options, PDQ’s 4200R exit device can be applied to any architectural style.
With its multiple certifications, it can guarantee reliable performance while keeping your building code compliant. Backed by a 5 year warranty, our 4200R rim exit device is a great product choice for your building's egress areas. Contact a local sales rep to learn about PDQ’s 4200R exit device.
Docs & Downloads:
Crafted for durability and security, PDQ’s 4200R exit device gives our customers a piece of mind while improving the appeal of their buildings.
- Choose from 6 different finishes: 605(US3), 626(US26D), 630(US32D), 689(US28), 695(SP313), 696(US4)
Easy to integrate into buildings, our 4200R rim exit device offers reliable protection without you having to sacrifice on style.
Features & Benefits
Certifications
The 4200R exit device carries an impressive range of certification, ensuring that our customers get a product that is reliable and compliant. Discover how our panic device meets the extensive industry requirements, protecting both the property and occupants.
- Its UL 305 certification guarantees superior quality
- It is UL 10C listed for 90-minute fire doors up to 3’ x 7’
- The exit device is also compliant with ADA (Americans with Disabilities Act) and ICC/ANSI 117.1 standards
Trust PDQ’s certified 4200R rim exit device, a reliable solution for almost any building application.
FAQs
How is the PDQ 4200R different from the 6300R?
The 4200R is PDQ's value-tier rim exit device, positioned as "the quality you need at the cost you like," with a shorter fire rating (UL listed up to 1-1/2 hours on doors up to 3' x 7'), compared to the 6300R's 3-hour, 4' x 10" rating and stated Grade 1 BHMA certification. Choose the 4200R for standard commercial single doors that don't require the 6300R's heavier duty tier or larger fire-rated sizing.
Is the 4200R rated for both panic and fire doors?
Yes, it carries UL 305 panic certification and a separate UL "Fire Exit Hardware" listing for up to 1-1/2 hours on doors up to 3' x 7' maximum size, so the same rim chassis serves both fire-rated and standard commercial openings, within that size limit.
What door widths and stile widths fit the 4200R?
It's designed as standard for 3-foot doors, with an option for doors up to 4 feet wide, and requires a minimum 4-1/4" stile for the device itself, a wider stile requirement than PDQ's 6300R because of the 4200's different chassis construction.
Can the 4200R be dogged open?
Hex key dogging is standard, but it's not available on fire-listed versions of the device, a common tradeoff on panic hardware, since a fire door can't be permitted to be held open in its latched position for code compliance.
What finishes are available for the 4200R?
Six finishes: 626 (satin chrome), 630 (satin stainless), 689 (aluminum), 695 (bronze), 696 (gold), and 605, giving a broader decorative-finish range (including bronze and gold options) than PDQ's 6300-series devices.
Specifications
View the products specifications chart to understand why our 4200R exit device is unique. Engineered for precision with strong materials, this exit device is a dependable solution for your commercial building.
| CHASSIS: |
• Corrosion resistant plated steel |
| RAIL: |
• Heavy gauge steel or stainless steel |
| LATCH: |
• RIM (R) – 3/4” throw* |
| BACKSET: |
• 2-3/4” Backset Compatible with 161 prep |
| HAND: |
• Device is non-handed |
| DOGGING: |
• Hex key dogging standard • Dogging not available on fire listed devices |
| MINIMUM STILE WIDTH: |
• 4-1/4”for device (exit only) • Minimum stile requirements with trim varies by trim type |
| DOOR THICKNESS: |
• 1-3/4” standard |
| DOOR WIDTH: |
• Standard for 3 ft doors, option available for doors up to 4’ |
| FINISHES: |
• 626 Satin Chrome, 630 – Satin Stainless Steel, 689 – Aluminum, 695 - Duro Bronze, 696 – Gold |
| FASTENERS: |
• Includes machine screws and wood screws • Sex nuts supplied with all Fire Listed devices |
| WARRANTY: |
• Five (5) year limited warranty |
| CERTIFICATIONS, LISTINGS, COMPLIANCES: |
• UL 305 listed for “Panic” , UL listed for “Fire Exit Hardware” labeled for up to 1-1/2 hours, 3’0” x 7’0” Max Size • Complies with ADA (Americans with Disabilities Act) and ICC/ANSI 117.1 for Accessible and Usable Buildings • TAA compliant. Country of origin: Taiwan |
Download our Section 08710 Specification here.
Finishes
Choosing an exit device to match the other hardware within your building can be challenging. Luckily, PDQ’s 4200R exit device comes in a wide range of durable finishes. Choose the perfect finishing touch for your project with our 4200R exit device.
